Selected Observing Notes from July 12 and 13th 2010 at the Golden State Star Party


Straight to my observing comments from my night observing on July 12 and 13th, 2010.  Pretty much straight out of my notebook.  This is only a partial list, a list of interesting and somehat challenging objects.

All objects listed here are in my downloadable observing guides.  Enjoy and hopefully you will try of these objects.

Equipment used:
22” f/4 reflector with no tracking
20mm Pentax XW finder eyepiece
12.5, 7mm Baader Genuine Orthoscopics
10 and 6mm Zeiss ZAO-II Orthoscopics
5mm Takahashi LE



July 12, 2010

GSSP

NELM = 6.9, Seeing = 3/5 for objects near the horizon and 4/5 for objects higher.





NGC 6302NGC 6302  (17 13 44.3  -37 06 13   size  85x44”   mag 12.8p  mag* 21.1)

22” (308 and 383x) – Very bright and structured.  Appears much like the photo.  The central area is too bright to attempt to pick off the central star. The east lobe is a little larger than the west lobe.  Two filaments are prominent on the east lobe.  1.4’ long and 0.4’ wide.  PA =90



Henize 2-289Henize 2-289  (17 49 48.2  -37 01 28   size 10”   mag 12.0p   mag* 16.8)

22” (308 and 383x) – Very small bright round glow with sharp edges. Located in a very star rich field.  The O-III filters helps a lot in identifying the planetary.  At 383x it starts to appear non-stellar. 1.2’ NW of a 3.7 mag star.  NGC 6441 lies 5.2’ due east of the star.



Henize 2-253Henize 2-253  (17 36 29.8  -39 21 57   size 18”   mag 14.4p   mag* -)

22” (308 and 383x) – Fairly bright even surface brightness round glow with defined edges.  It was barely visible without the O-III filter.  The filter brings it out very well.  0.3’ across.  A 9.6 mag star lies 1.5’ west.



Minkowski 1-28Minkowski 1-28  (17 47 38.4  -22 06 20   size 15”   mag 16.8p   mag* 20.8)

22” (308 and 383x) – Very faint round glow visible only with the O-III filter.  About 0.3’ across.  A pair of 12th magnitude stars lies 1.3’ west.



NGC 6439NGC 6439  (17 48 20.3  -16 27 35   size 5”   mag 13.8p   mag* 20.2)

22” (308 and 383x) – Bright nearly stellar object.  With the O-III filter, it appears about as bright as the nearby mag 12.3 star that lies 1.2’ north.  It becomes distinctly non-stellar at 383x.  About 5” across.  Note: MegaStar incorrectly labels the 12.3 mag star as the PNe.



NGC 6445NGC 6445  (17 49 14.9  -20 00 36   size 44x30”   mag 13.2p   mag* 19.0)

22” (308 and 383x) – Appears like a faint dumbbell with two arcs at opposite ends (NW and SE)  A 3:2 elongated glow with two bright lobes.  The NW lobe is slightly larger than the SE lobe, but the SE lobe is brighter.  About 0.8’ long and 0.5’ wide.  PA = 135   A 12.5 mag star lies 0.8’ NW and a 12.0 star lies 2.1’ due south.



NGC 6765NGC 6765  (19 11 06.8  +30 32 39  size 40”’   mag 13.1p   mag* 16.0)

22” (308 and 383x) – A bi-polar planetary.  PA = 30.  The north lobe is significantly larger than the south lobe.  The north lobe has a 0.2’ long bright part and the south lobe contains a 0.1’ round part.  The PNe is 0.7’ long.  A pair of faint stars at the SW edge and another pair of very faint stars at the NE end.



Kohoutek 3-27Kohoutek 3-27  (19 14 30.2  +28 40 43   size 16”   mag 14.9p   mag* 17.2)

22” (308 and 383x)  - Very faint small round glow with defined edges picked up pretty easily with the O-III filter..  About 0.2’ across.  A blazing 8.1 mag star lies 2.7’ due west and a 11.8 mag star lies 1.3’ north.



MCG-1-53-12MCG-1-53-12  (20 49 52.1  -07 01 18   size 3.0x0.3’   mag 14.6)

22”  (186 and 230x) – Very faint, thin even surface brightness glow with diffuse edges.  No central brightening.  1.3’ long and PA = 0.  A 14.3 mag star lies 1.1 a little north of west from the center.  A pair of 13-14th mag stars lies just under 2’ to the NE.



July 13, 2010

GSSP

NELM = 7.0, Seeing = 3/5 for objects near the horizon and 4/5 for objects higher.


Wray 16-282Wray 16-282  (17 31 47.3  -28 42 04   size 37”   mag 14.9p   mag* -)

22” (308x) – Very faint 3:2 elongated glow with diffuse edges.  Even surface brightness throughout.  0.3’ long and PA = 90.



Minkowski 1-22Minkowski 1-22  (17 35 10.1  -18 34 20   size 9”  mag 13.3p  mag* -)

22” (383x) – Slightly elongated glow.  About 0.15’ long and PA = 90.  Three stars in a row.  Responds well with O-III filter.



Henize 2-260Henize 2-260  (17 38 57.4  -18 17 35   size 10”  mag 11.0v  mag* 14.2)

22” (383x) – Nearly stellar.  Mild response to the O-III filter.  About 5” across.  A row of 4 16th magnitude stars lies 30” north.



Henize 2-261Henize 2-261  (17 39 54.8  -21 14 14   size 17”   mag 15.3p  mag* -)

22” (308 and 383x) – Faint round glow with diffuse edges.  The O-III filter brings it out.  0.2’ across.  A 16th magnitude star lies just off the SE edge.



Henize 2-264Henize 2-264  (17 40 26.8  -27 01 03   size 37”   mag -   mag* 20.3)

22” (308 and 383x) – Very faint irregular glow just SW of a mag 12.2 star.  I could not make out the shape, but it definitely looks irregular with two slightly brighter arcs at the north and south edges.  A small triangle of 11 to 14th mag stars lies about 2’ NE.



PK 28+10.1PK 28+10.1  (18 06 00.5  +00 22 43   size 36”  mag 16.8p  mag* 16.8)

22” (186x) – Very faint round glow with diffuse edges.  O-III only.  About 0.6’ across.  A very faint star is just off the SW edge.



Kohoutek 1-16Kohoutek 1-16  (18 21 52.2  +64 21 53   size 1.9’  mag 14.5p  mag* 15.0)

22” (186, 308 and 383x) – located the star field, but did not see the nebula.  O-III filter was used too.



Henize 1-4Henize 1-4  (19 59 18.5  +31 54 34   size 22”   mag 14.1   mag* 21.1)

22” (186, 230, 308 and 383x) 0 Faint, oval with a 10.6 mag star on the SE tip.  PA = 135.  About 0.4’ long and 0.3’ wide.  Fairly well defined edges.



Kohoutek 3-46Kohoutek 3-46  (19 50 00.3  +33 45 53   size 30”   mag 16.4p  mag* -)

22” (186, 308 and 383x) – located the star field, but did not see the nebula.  O-III filter was used too.



NGC 6857NGC 6857  (20 01 48.7  +33 31 32  size 38”   mag 11.4p)

22” (186x) – Appears much fainter than the DSS image.  Irregular box shape, about 1’ square.  Very rich star field.



NGC 6822

Hubble VII


Hubble VII in NGC 6822  (19 44 55.8  -14 48 55   size ~6”   mag -)

18” (328x with 6mm ZAO-II) – Stellar, field found fairly easily.  A faint star is just 6” SSE.  Steve Gottleib and I used a detailed image to star hop there…it took a little while to fish it out in the sea of stars.  It appeared just non-stellar at 328x.
